Cahit Oruc Agricultural Machinery
- Tandem axle, field type manure spreader
- 2 dispenser disks
- Case sheet thickness 3 mm
- Base sheet thickness 4 mm
- Trailer track width 168 cm
- Operation PTO : 540 rpm
- Working width : 30 mt
- Tire Size: 12.5/80 - 15.3
- Drive chain type, 13mm German Origin
- Drive system operation type, hydraulic
- Distributor system operation type, PTO : 540 rpm

With 8 capacity options;

5 m³ - 5.2 mt x 2.08 mt x 2 mt
6 m³ - 5.2 mt x 2.08 mt x 2.2 mt
8 m³ - 6.3 mt x 2.08 mt x 2.08 mt x 2.65 mt
10 m³ - 6.6 mt x 2.08 mt x 2.08 mt x 2.85 mt
12 m³ - 6.6 mt x 2.08 mt x 3.05 mt
15 m³ - 6.9 mt x 2.25 mt x 2.95 mt
18 m³ - 7.3 mt x 2.4 mt x 3.25 mt
20 m³ - 7.3 mt x 2.4 mt x 3.5 mt

Overall dimensions :

Standard parts:
1 - Hand wash tank
2 - Tool cabinet
3 - Reflective application
4 - Electrical installation and stop lamp
5 - Hydraulic tailgate system

NOTE: MODEL IN PHOTO IS 10m³ MODEL.
