Horizontal Type Milk Cooling Tank 4000 Lt.
- Completely made of AISI 304 quality stainless steel
- 1st wall base is 2mm and 0,8 mm Ep type heat transfer plate is coupled with wall
- Isolation wall is 1,2 mm AISI 304 quality stainless steel
- 1 piece special design 0,34 HP 0,34 rpm gearbox and stainless steel agitator coupled with gearbox. Agitator is designed according to milk structure protection
- Product Outlet DN 50 male butterfly valve
- Insulation material; HCFC free water based high density polyurethane foam and isolation thickness is 65 mm.
- AISI 304 quality stainless steel Ø 500 mm manhole cover and Ø 100 mm product inlet exist
- Manual with measuring table and calibrated for each tank
- Spring cover system and Ø 200 mm product inlet.
- Special manual scale with 3-4 ‰ sensitivity rate
- 1 piece stainless steel ladder
- Ø 90 air vent
- AISI 304 quan
- Designed to leave 0 liquid in the tank after discharge
- Tank body coupled on whole chassis
- Welding; Argon Tig welding system applied and welded areas are 1 st class smoothly polished
- Cooling evaporator (rollbond) is tested against 40 bar test pressure.
Capacity 4000 lt.
Class 2BII
Model P.H.S./Y.4000 LT
Automatic Washing Available
Scale Available
Material 304 K. Stainless
Isolation Material 60 mm Polyurethane
Compressor Power 2x7 Hp - (12,6 kW)
Membrane Number 2
