YVP-500
The suction capacity of YVP 500 vacuum pump is 500 lt / min at 50 kPa (37.5 cm / Hg). The pallet material of the pump is fiber. The vacuum pump is designed to be used in fixed milking systems and it can milk 220 V 2 Hp 6 cattle, 12 sheep, goat 380 V 3 Hp 8 cattle, 16 sheep and goats. There are 2 Hp - 1500 d / d - 220 V (Single-phase) or 3 Hp-1500 d / d -380 V (Three-phase) electric motor options in the drive of the vacuum pump.
FLOW 500 LT / MIN.
POWER 2 HP (220 V)
PUMP SPEED 1200 D / D.
ELECTRIC MOTOR PULLEY SIZE 13x100xI
PUMP PULLEY SIZE 13x120xII
BODY AND ROTOR CASTING (GG SERIES)
PALLET TYPE FIBER
PALLET SIZE 110x55x5.75 MM.
WEIGHT 23 KG
